型号 |
流量 (m3/h) |
扬程 (m) |
转速 (r/min) |
轴功率 (kW) |
电动机 |
效率 (%) |
必需汽蚀余量 NPSH(r)(m) |
|
|
功率(KW) |
电机型号 |
|||||||
|
KTB100-65-210 |
35 55 66 |
15.3 14 13 |
1450 |
2.31 2.87 3.2 |
4 |
Y112M-4S |
63 73 73.5 |
1.9 2.0 2.3 |
|
KTB100-65-250 |
30 50 60 |
21.3 20 19 |
1450 |
3.16 4 4.44 |
5.5 |
Y132S-4S |
55 68 70 |
2.0 2.3 2.5 |
|
KTB100-65-260 |
36 60 72 |
24.5 22.5 20.6 |
1450 |
4 5.25 5.77 |
7.5 |
Y132M-4S |
60 70 69 |
2.0 2.3 3.0 |
|
KTB100-65-315 |
30 50 60 |
34 32 30 |
1450 |
5.44 6.92 7.67 |
11 |
Y160M-4S |
51 63 64 |
1.9 2.0 2.5 |
|
KTB100-65-315A |
28.5 48 58 |
31 28 27 |
1450 |
4.74 6 6.7 |
7.5 |
Y132M-4S |
51 63 64 |
1.9 2.0 2.5 |
|
KTB100-65-320 |
40 65 78 |
37 34 31 |
1450 |
7.46 9.56 10.62 |
15 |
Y160L-4S |
54 63 62 |
1.9 2.0 2.5 |
|
KTB100-65-320A |
37 62 74.5 |
33.4 30.9 28 |
1450 |
6.73 8.54 9.47 |
11 |
Y160M-4S |
50 61 60 |
2.5 2.5 3.0 |
|
KTB125-100-200 |
60 100 120 |
14.5 12.5 11 |
1450 |
3.84 4.48 4.79 |
7.5 |
Y132M-4S |
62 76 75 |
2.5 2.5 3.0 |
|
KTB125-100-200A |
56 93.5 112 |
12.8 11 9.7 |
1450 |
3.17 3.7 3.96 |
5.5 |
Y132S-4S |
62 76 75 |
2.5 2.5 3.0 |
|
KTB125-100-250 |
60 100 120 |
21.5 20 18.5 |
1450 |
5.59 7.17 7.84 |
11 |
Y160M-4S |
62 76 77 |
2.5 2.5 3.0 |
|
KTB125-100-250A |
56 93.5 112 |
18.8 17.5 16.2 |
1450 |
4.56 5.87 6.41 |
7.5 |
Y132M-4S |
63 76 77 |
2.5 2.5 3.0 |
|
KTB125-100-250B |
52.2 86.5 104 |
16 15 13.9 |
1450 |
3.7 4.86 5.17 |
5.5 |
Y132S-4S |
62 75 76 |
2.5 2.5 3.0 |
|
KTB125-100-315 |
60 100 120 |
33.5 32 30.5 |
1450 |
9.4 11.9 13.5 |
15 |
Y160L-4S |
58 73 74 |
2.5 2.5 3.0 |
|
KTB125-100-315A |
57.4 95.5 114 |
30.5 28.5 27.8 |
1450 |
8.22 10.33 11.7 |
15 |
Y160L-4S |
58 73 74 |
2.5 2.5 3.0 |
|
KTB125-100-315B |
54.6 90.8 108.9 |
27.7 26.4 25.8 |
1450 |
7.23 9.08 10.5 |
11 |
Y160M-4S |
57 72 73 |
2.5 2.5 3.0 |
|
KTB125-100-400 |
60 100 120 |
52 50 48.5 |
1480 |
16.1 21 23.6 |
30 |
Y200L-4S |
53 65 67 |
2.5 2.5 3.0 |
|
KTB125-100-400A |
56 93.6 112.4 |
46 44 43 |
1480 |
13.2 17.5 19.6 |
22 |
Y180L-4S |
53 64 67 |
2.5 2.5 3.0 |
|
KTB125-100-400B |
52.2 88 105 |
40 38 37.2 |
1480 |
11.2 14.6 16.4 |
18.5 |
Y180M-4S |
51 62.8 65 |
2.5 2.5 3.0 |
|
KTB125-100-210 |
90 142 170 |
15 13 11.5 |
1480 |
5.25 6.36 6.91 |
11 |
Y160M-4S |
70 79 77 |
2.2 2.5 3.4 |
|
KTB125-100-260 |
95 148 175 |
24.5 22 20 |
1480 |
9.19 11.37 12.54 |
15 |
Y160L-4S |
69 78 76 |
2.3 2.6 3.5 |
|
KTB125-100-320 |
80 146 165 |
37.5 34 29 |
1480 |
12.73 16.7 18.38 |
22 |
Y180L-4S |
65 75 72 |
2.0 2.0 2.3 |
|
KTB125-100-320A |
78 142 165 |
32 28 25 |
1480 |
10.8 14.83 16.28 |
18.5 |
Y180M-4S |
63 73 69 |
2.0 2.0 2.3 |
|
KTB125-100-410 |
90 150 176 |
57 52 48.5 |
1480 |
24.08 31.24 34.96 |
45 |
Y225M-4S |
58 68 67 |
2.3 2.5 3.2 |
|
KTB125-100-410A |
87 144 172 |
52 48 44 |
1480 |
22 28.5 31.7 |
37 |
Y225S-4S |
56 66 65 |
2.3 2.5 3.2 |
|
KTB125-100-410B |
83 140 165 |
45 40 38 |
1480 |
18.83 23.8 27.1 |
30 |
Y200L-4S |
54 64 63 |
2.3 2.5 3.2 |
|
KTB150-125-250 |
120 200 240 |
22.5 20 17.5 |
1480 |
10.4 13.5 14.7 |
18.5 |
Y180M-4S |
71 81 78 |
3.0 3.0 3.5 |
|
KTB150-125-250A |
112 187 224 |
19.5 17.5 15.2 |
1480 |
8.7 11.3 12.3 |
15 |
Y160L-4S |
68 77.9 75.3 |
3.0 3.0 3.5 |
