型号 |
流量 |
扬程 (m) |
转速 (r/min) |
功率(kW) |
效率 (%) |
必需汽蚀余量 (NPSH)r(m) |
口径(mm) |
吐出锥管口径 (mm) |
|||
|
m3/h |
l/s |
轴功率 |
配用功率 |
吸入 |
排出 |
||||||
|
IZ50-32-125 |
7.5 12.5 15 |
2.08 3.47 4.17 |
22 20 18.5 |
2900 |
0.96 1.13 1.26 |
2.2 |
47 60 60 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-125A |
7 11.2 13.5 |
1.94 3.11 3.75 |
18 16 14 |
2900 |
0.77 0.86 0.92 |
1.5 |
44 57 56 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-160 |
7.5 12.5 15 |
2.08 3.47 4.17 |
34.3 32 29.6 |
2900 |
1.59 2.02 2.16 |
3 |
44 54 56 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-160A |
7 11.8 14 |
1.94 3.28 3.89 |
30.3 28 26 |
2900 |
1.37 1.74 1.86 |
2.2 |
42 51.7 53.3 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-200 |
7.5 12.5 15 |
2.08 3.47 4.17 |
52.5 50 48 |
2900 |
2.82 3.54 3.95 |
5.5 |
38 48 51 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-200A |
7.2 12 14.4 |
2 3.33 4 |
47.3 45 43.2 |
2900 |
2.49 3.13 3.5 |
5.5 |
37 47 48.4 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ50-32-200B |
6.5 10.8 13 |
1.81 3 3.61 |
39.8 38 36.4 |
2900 |
1.91 2.39 2.68 |
3 |
37 47 48 |
2.0 2.0 2.5 |
50 |
32 |
32-50 |
|
IZ65-50-125 |
15 25 30 |
4.17 6.94 8.33 |
21.8 20 18.5 |
2900 |
1.54 1.97 2.22 |
3 |
58 69 68 |
2.0 2.0 2.5 |
65 |
50 |
50-65 |
|
IZ65-50-160 |
15 25 30 |
4.17 6.94 8.33 |
35 32 30 |
2900 |
2.65 3.35 3.71 |
5.5 |
54 65 66 |
2.0 2.0 2.5 |
65 |
50 |
50-65 |
|
IZ65-50-160A |
14 23.5 28 |
3.89 6.53 7.78 |
30.5 27.8 26 |
2900 |
2.24 2.83 3.13 |
4 |
52 64 63.3 |
2.0 2.0 2.5 |
65 |
50 |
50-65 |
|
IZ65-40-200 |
15 25 30 |
4.17 6.94 8.33 |
53 50 47 |
2900 |
4.42 5.67 6.29 |
7.5 |
49 60 61 |
2.0 2.0 2.5 |
65 |
40 |
40-65 |
|
IZ65-40-200A |
14 23.4 28 |
3.88 6.5 7.77 |
46.5 44 41 |
2900 |
2.2 4.6 5.14 |
5.5 |
49 60 61 |
2.0 2.0 2.5 |
65 |
40 |
40-65 |
|
IZ65-40-250 |
15 25 30 |
4.17 6.94 8.33 |
82 80 78 |
2900 |
9.05 10.89 12.02 |
15 |
37 50 53 |
2.0 2.0 2.5 |
65 |
40 |
40-65 |
|
IZ65-40-250A |
14 23.4 28 |
3.89 6.5 7.78 |
72 70 68 |
2900 |
7.65 9.1 10 |
11 |
36 49 52 |
2.0 2.0 2.5 |
65 |
40 |
40-65 |
|
IZ80-65-125 |
30 50 60 |
8.33 13.9 16.7 |
22.5 20 18 |
2900 |
2.87 3.68 3.98 |
5.5 |
64 75 74 |
3.0 3.0 3.5 |
80 |
65 |
65-80 |
|
IZ80-65-125A |
28 46.7 56 |
7.78 12.9 15.5 |
18.6 16.6 14.9 |
2900 |
2.34 2.96 3.25 |
4 |
66.6 72 70 |
3.0 3.0 3.5 |
80 |
65 |
65-80 |
|
IZ80-65-160 |
30 50 60 |
8.33 13.9 16.7 |
36 32 29 |
2900 |
4.82 5.97 6.59 |
7.5 |
61 73 72 |
2.5 2.5 3 |
80 |
65 |
65-80 |
|
IZ80-65-160A |
28 46.8 56 |
7.78 13 15.6 |
31.4 28 25.3 |
2900 |
3.93 4.9 5.4 |
5.5 |
61 73 72 |
2.5 2.5 3 |
80 |
65 |
65-80 |
|
IZ80-50-200 |
30 50 60 |
8.33 13.9 16.7 |
53 50 47 |
2900 |
7.87 9.87 10.8 |
15 |
55 69 71 |
2.5 2.5 3 |
80 |
50 |
50-80 |
|
IZ80-50-200A |
28 46.8 56 |
7.78 13 15.6 |
47 44 41 |
2900 |
6.66 8.25 9 |
11 |
54 58 70 |
2.5 2.5 3 |
80 |
50 |
50-80 |
|
IZ100-80-125 |
60 100 120 |
16.7 27.8 33.3 |
24 20 16.5 |
2900 |
5.86 7 7.28 |
11 |
67 78 74 |
4 4.5 5 |
100 |
80 |
80-100 |
|
IZ100-80-125A |
56 93.5 112 |
15.6 26 31.7 |
20.3 17 14 |
2900 |
4.79 5.73 5.95 |
7.5 |
64.8 75.6 71.7 |
4 4.5 4.5 |
100 |
80 |
80-100 |
|
IZ100-80-160 |
60 100 120 |
16.7 27.8 33.3 |
36 32 28 |
2900 |
8.42 11.2 12.2 |
15 |
70 78 75 |
3.5 4 5 |
100 |
80 |
80-100 |
|
IZ100-80-160A |
56 93.5 114 |
15.6 26 31.7 |
31.5 28 24.5 |
2900 |
6.99 9.27 10.3 |
11 |
69 77 74 |
3.5 4 5 |
100 |
80 |
80-100 |
